Multi-functional Popular Bean Peeling Machine|Walnut Peeling Machine

Material: bean ,nut

Capacity: 400-1500kg/h,can be customized

Loading Port: Qingdao port

Description:

It can be used to remove the skin of various beans such as broad bean,soybean,pea,black bean,etc.With capacity 400-1500kg/h,can be customized

Share this Facebook LinkenIn Twitter Google+ Youtube
There is one set sand dies installed internal machine, one is fixed, another is moving, the beans pass through the high speed moving die, the hard shell will be taken away under the strong friction, then the complex material enters into the vibrating sieves for separating, the air fan will suck the shells and then the clear peeled seed(in half) flow out from another side of peeler.It can peal all kinds of bean like soybean , pea ,horse bean ,mung bean and so on,and separate two kernel at the same time .During peeling, it can separate into two kernel at the same time. High peeling rate.according to the sort and size of soybean, we can adjust the space so that the disc life cycle is expanded. The parts that touches the raw material are made of stainless steel, the rest are made of coal rolling steel sheet or A3 steel.
bean peeling machine
Advantages of the bean peeling machine:
It applies for peeling kinds of round shape bean soybean, mung bean, green bean, etc; it is multifunctional including peeling and separating, sorting together, the shell and skin can be separated and sorted after peeling, so we can get clean and pure bean kernel after processing by this machine unit, it is high peeling rate, large capacity, automatic processing from feeding, grinding to final bean kernel product .This Black gram black skin removing machine has many advantages, such as energy saving, high production capacity,high recycle, long working life, convenient operation, few operators, up to the national standard of energy saving and no pollution.
Model GGDP-1 GGDP-2
Motor 1.5+0.39 4+0.75+0.39
Disc diameter(mm) 500 500
Peeling Rate >95% >95%
Capacity(kg/h) 400-600 1000-1500
Net weight(kg) 300 400
Dimension(mm) 600*1400*2000 600*1400*2000
Moisture <12-14% <12-14%
