Essential Information

Hydraulic oil press machine is mainly used for cocoa, sesame, canola, almond, sunflower seeds, rapeseed sesame canopy til seed camellia seed cotton seed pricklyash seed Walnut kernel etc, which is convenient to use, the squeezing for operation.
Main components of Hydraulic oil press machine: The piston, hydraulic cylinder, pillar, pedestal, oil pump, cylinder, electric heating circle, and automatic temperature control device, etc.Material adopt high quality metal materials, and improve the machine performance, ensure the service life of parts. The hydraulic oil press machine is simple operation, high oil press rate, each pack 6-8 kg, 8-10 mintes.

automatic oil extractor machine

Advertage of the machine:
1.The machine is small in size, small in floor space, easy to learn, easy to understand, easy to operate, and has no special requirements for operators.

2.During the use of this machine, the power consumption is low and the various expenses are small.

3.Than stone grinding, saving power.

4.This machine belongs to hydraulic machine with high pressure, high oil yield and good oil quality.

5.This machine adopts automatic control system, preheating temperature automatic control and hydraulic system pressure automatic control.

6.The main components of the machine are made of imported high-quality silicon-manganese steel, equipped with CNC precision lathe and modern new technology. The whole machine has good performance.
Video:

The oil yield of the different raw materials:

1.Sesame:It takes 4-10 minutes to complete the oil extraction, and the oil can be extracted from 1-15 kg sesame each time. The output for 10 hours is 150-1200 kg, and the oil yield is 42%-52%.

2.Almond:It takes 4-10 minutes to complete the oil extraction, and the oil can be extracted from 1-14 kg almond each time. The output for 10 hours is 150-1000 kg, and the oil yield is 40%-45%.

3.Walnut:It takes 4-10minutes to complete the oil extraction, and the oil can be extracted from 1-14kg almond each time. The output for 10 hours is 150-1000 kg, and the oil yield is 50%-60%.

4.Pine nuts:It takes 4-10 minutes to complete the oil extraction, and the oil can be extracted from 1-14kg almond each time. The output for 10 hours is 150-1000 kg, and the oil yield is 45%-60%.

Technical Data

Model	GGZY-180	GGZY-230	GGZY-260	GGZY-280	GGZY-320
Dimensions	8006501100	9007501400	9009001450	90010001500	90011001650
Machine weight	530kg	880kg	1200Kg	1500kg	2000Kg
Nominal pressure	1600KN	2200KN	2600KN	3000KN	3500KN
Use work pressure	55Mpa	55Mpa	60Mpa	60Mpa	60Mpa
Electric heating coil power	1KW	1KW	1KW	2KW	3KW
Heating coil control temperature	70-100°C	70-100°C	70-100°C	70-100°C	70-100°C
Add sesame each time	1-3kg	2-7kg	3-11kg	5-15kg	10-20kg
Motor model power	Y901-6-1.5kw	Y901-6-1.5kw	Y901-6-2.2kw	Y901-6-2.2kw	Y901-6-4.0kw
