Dried Lemon Fruit Chips Processing Machine Supplier

  • Brand:GELGOOG
  • Capacity:Can be customized
  • WhatsApp: +8618537181190


Dried lemon chips processing machine adopt a special high-volume axial flow fan to work independently, through the built-in electric heating tube, equipped with high-power thyristor controller, PID digital display intelligent temperature controller, can be used to process dried lemon, banana, kiwi, berries, mushroom, moringa leaf, ginger/garlic slices. onion flakes, noodles, okra, dates, etc

dried lemon chips machine
Processing steps of lemon slices:
1. Select high-quality lemon fruit, carefully clean the lemon fruit, there are salt water cleaning method, soda water cleaning method or ultrasonic cleaning method and so on. The main purpose is to clean and remove pesticide residues or wax.
2. Use manual or lemon slicer to cut the fruit into slices of about 4mm, pay attention to the thickness to be even, the error should not exceed ±1mm! In addition, the lemon seeds should be removed to avoid affecting the drying effect and the taste of lemon slices.
3. Place the lemon slices neatly on a ventilated tray, avoid stacking them, first use natural wind and light to remove some of the water from the lemon slices.
4. Transfer the lemon slices that have been air-dried for one day to a high-temperature air-energy lemon drying room, and set the dryer temperature to a low temperature range of 40-50°C. The water in the lemon slices will slowly evaporate and be discharged during the low-temperature drying process. The process takes about 15 hours.
5. Mass drying of lemon slices pays attention to quality, environmental protection, efficiency, and the simplicity and safety of machine operation. During the drying process, it pays attention to the precise control of temperature, humidity, air volume, and wind speed. If you want to dry other fruit slices, such as apple slices, mango slices, banana slices, dragon fruit slices, hawthorn slices, etc., the main points are also inseparable.
lemon drying machine factory
 Main features of lemon chips drying machine:
※ The whole box adopts a fully enclosed structure, and the hot air box circulates, which is energy-saving and high-efficiency.
※The use of built-in high temperature resistant circulating fan greatly reduces heat loss and strengthens heat transfer.
※There is an adjustable air equalizing plate in the box, which can adjust the opening up and down to make the temperature in the box up and down evenly.
※The thickness of the insulation layer is 80mm, and the material is white ultra-fine glass wool, which meets GMP standards and has low heat loss.
dried fruit chips making machine

Technical Data

Model HX1-1 HX2-2 HX2-4 HX3-6 HX4-8
Qty of dryer 1 2 4 6 8
Qty of drying tray 24 48 96 144 192
Circulating fan 1 1 2 3 4
hydrofuge fan 1 1 1 1 2
Power 12 18 30 48 60
Dimension(meters) 1.6x1.2x2.35 2.5x1.2x2.35 2.5x2.2x2.35 3.5x2.2x2.35 4.8x2.2x2.35
Net weight( 470 760 1000 1650 2000
Packing dimension(meters) 1.72x1.36x2.26 2.63x1.36x2.26 2.63x2.26x2.26 3.63x2.26x2.26 4.93x2.26x2.26
Packing weight 520 830 1100 1800 2150
Capacity(kg) 72 144 288 432 576
