Multi-purpose Powder Grinding Machine|Small Salt Sugar Chili Spices Grinder

Material: rice,salt,sugar,chili,spices,herbal,etc

Capacity: 60-1500kg/h

Loading Port: Qingdao port

Description:

Stainless steel multi-purpose powder grinder is with wide application and is wide used for pharmaceutical industry,chemical industry,foodstuff industry,grain industry and so on

Share this Facebook LinkenIn Twitter Google+ Youtube
Stainless steel multi-purpose powder grinder is with wide application and is wide used for pharmaceutical industry, chemical industry, foodstuff industry, grain industry and so on. Stainless steel Grinder uses the relative motion between movable and fixed teeth disc, the raw materials to be crushed undertakes the comprehensive actions such as impacted by teeth, friction, impacted between raw materials are crushed. Its features are simple and solid in structure, stable in operation.
sugar powder grinder
Stainless steel powder grinder machine is made of 304 stainless steel material production, casing internal (crushing slot) all tooth surface precision machining so as to achieve smooth, easy to clean, to change the ordinary.
GELGOOG offer common model with function optional: Common model + dust remover + water cooling system.


Model GGS180B/C GGS20B/C GGS30B/C GGS40B/C GGS50B/C GGS60B/C
Capacity(KG) 5-20 50-100 50-200 100-400 200-500 200-800
Discharge fineness 20-120 20-120 20-120 20-120 20-120 20-120
Cutter diameter(mm) 150 200 300 350 500 550
monitor rate(KW) 1.5 4.0 5.5 11.0 15.0 18.5
Dust removal power(KW)   0.55 0.75 1.1 1.5 2.2
Total Weight(KG) 60 140 220 440 560 620
Dust removal weight(KG) 110 230 310 560 680 760
Dimensions(mm) 450*350*950 600*500*1170 750*600*1370 800*700*1450 850*950*1550 900*1100*1750
Dust removal size(mm) 800*500*1200 1000*500*1400 1200*700*1850 1350*900*2000 1400*900*2150 1600*1100*2300

  • Automatic Sugar Cube Machine|Coffee Sugar Production LineAutomatic Sugar Cube Machine|Coffee Sugar Production Line
