Automatic Fish Sorting Grader Machine by Weight

  • Brand:GELGOOG
  • Capacity:100pieces/min
  • WhatsApp: +8618537181190


This automatic fish sorting grader machine can be used to process various fresh fish and seafood, poultry meat raw food processing, automotive hydraulic accessories precise classification. Also can be uesd to sort other products, like chicken wings, chicken feet, seashells, scallop, shellfish, clam etc.
fish sorting machine
Main features of automatic fish sorting grader machine:
1.The use of imported special dynamic weighing unit to achieve high-speed stable measurement;
2.10 inch large size color touch screen interface, simple operation, intuitive display;
3.Automatic sorting, eliminating human error;
4.English and Chinese bilingual design;
5.Automatic zero analysis and tracking system to ensure the detection stability;
6.Embedded temperature noise compensation system to ensure reliable data;
7.powerful data statistics, record the daily test data, can store 100 sets of product data to facilitate customer calls, and a sudden power failure data will not be lost;
8.Conveyor system adopts frequency control mode to facilitate the speed before and after;
9. Dynamic weight compensation technology, testing data more real and effective;
10.Self-diagnosis and prompt function to facilitate maintenance;
Reinforced stainless steel 304 frame, in line with GMP and HACCP specifications.
GELGOOG also offer Fish Gutting Machine

Technical Data

Model  GGHXCW-220-6/GGHXCW-220-8
Conveyor dimension Length 500mm*width220mm
Distance between the conveyor and floor 700±50mm(can be customized)
Controller  10 inches color touch screen
Conveying direction  In the face of operation panel, from right to left or from left to right
Fish Size Range length≤350mm*width≤200mm
Weight range 250-400g
Sorting grade 6 or 8 grading
Testing precision  ≤±2g
Nonconforming product dealing way Sliding plate / box type (confirmed according to customer requirements)
Testing speed 100pieces/min
Grading way Rodless cylinder
zero-tracking zero-tracking automatically
Number of store recipe 100 pieces/per minute
Type of alarm Buzzer, alarm lamp(can be setted)
Test products Frozen fillets and fresh fish
Machine Material Main frame and standard parts for the 304 stainless steel
Degree of protection IP65 dustproof and waterproof standards
Suitable Temparature 0-40 degree
to ensure accuracy, temperature changes do not exceed ± 5 ° C / h
Voltage 220V±10% 50HZ   500W
