Fried Sweet Potato Yam Chips Production Line

  • Brand:GELGOOG
  • Capacity:50-200kg/h
  • WhatsApp: 008618537181190


The main equipment of fried yams production line includes yam washing peeling machine,slice cutting machine, rinsing machine, yam chips fryer, vibration deoiling machine, seasoning machine and packaging machine. GELGOOG offers the full set of yam chips production line, it can also be used for making potato chips, sweet potato chips, beet chips, etc.
By changing the cutting machine, the machine can also make potato french fries, sweet potato fries, etc
sweet potato chips production line
Main produciton process of making fried chips:
 ♥Raw material selection: Choose fresh potatoes with high dry matter content, requiring pure varieties, shallow sprouts, regular shapes, no mildew, rot, germination and insect pests, and a diameter between 50-70mm.
 ♥Cleaning & Peeling: Use a cleaning machine to remove debris and other debris from the raw materials. Using mechanical friction peeling method, 30-40kg at a time, peeling time depends on the freshness of the raw materials, generally 3-8min. The peeled potatoes are required to be clean and smooth in appearance. The peeling time should not be too long to avoid excessive peeling and increase the material loss rate.
 ♥Chips Slicing: Feed the raw materials into the slicer one by one, the feeding speed should be uniform, and the slice thickness should be between 1~2mm.
 ♥Rinsing: The sliced ​​potato chips must be immersed in water for rinsing to prevent the potato chips from oxidizing and browning in the air. At the same time, the free starch on the surface of the potato chips is washed away to prevent the starch from dissolving into the oil pan and affecting the life of the frying oil.
 ♥Dehydration: Spread the stacked materials on the distributor to avoid increasing the frying time and increase the oil content of the finished product.
 ♥Chips frying: The flakes should enter the frypot evenly, the oil temperature should be controlled between 180~200℃, and the materials must pass through the frypot within 2 minutes. Palm oil is mostly selected for frying oil. Compared with other edible oils, it has the characteristics of good stability, long service life and good shortening performance. It is especially suitable for frying oil.


 ♥De-oiling: After frying the flakes, the remaining oil is removed by a vibration de-oiling machine, which can extend the product shelf life.
 ♥Seasoning: After being tasted by a seasoning machine, fried potato chips with different flavors are made. According to different taste requirements, potato chips can be made with chicken flavor, beef flavor, spicy flavor and barbecue flavor.
 ♥Chips packaging: The product must be packaged in quantitative quantities, with a net content error of <±10%>. In order to extend the shelf life, aluminum-plastic composite bags are mostly vacuum-filled with nitrogen.
sweet potato chips production line
GELGOOG sweet potato yams chips making machine is with simple structure, convenient operation and long service life. Compressed by imported equipment and stainless steel spring wire, the surface is flat, and the width of the mesh belt can be selected according to requirements. Optional output like 50kg/h, 100kg/h, 200kg/h according to customers' needs. The full set of yam chips making machine is made of stainless steel to ensure cleanliness and hygiene.

Technical Data

Name Parameters
Potato Washer and Peeler Machine Power: 0.75kw  Voltage: 380V-3/220V-3
Weight: 90KG
Size: 650*550*800mm
Capacity: 200KG/H
Potato Cutter
Power: 1.1kw
Weight: 110KG
Size: 950*900*1000mm
Capacity: 600KG/H
Blanching Machine Power: 9kw
Volts: 380v-3/220v-3    Weight: 80KG
Size: 700*700*900mm
Capacity: 60KG/H
Dewater Machine
Power: 1.5kw
Volts: 380v-3/220v-3    Weight: 300KG
Size: 900*500*800mm
Capacity: 200KG/H
Pottato Frying Machine Power: 12kw
Volts: 380v-3/220v-3    Weight: 80KG
Size: 700*700*900mm
Capacity: 20KG/H
De-oiling Machine Power: 1.1kw
Volts: 380v-3/220v-3    Weight: 300KG
Size: 900*500*800mm
Capacity: 200KG/H
Potato Flavoring Machine Power: 1.1kw
Volts: 380V-3/220V-3
Weight: 150KG
Size: 1100*800*1300
Capacity: 200KG/H
Vacuum Packing Machine Power: 1.1kw
Volts: 380V-3/220V-3
Weight: 80kg
Size: 500*500*800mm
Capacity: 20KG/H
