Penumatic Quantitative Sausage Filling Machine

Material: sausage

Capacity: 60-80g/min

Loading Port: Qingdao port

Description:

Penumatic Quantitative Sausage Filling Machine adopts international advance technology, using compressed air as the power and microcomputer controlled.

Penumatic Quantitative Sausage Filling Machine adopts international advance technology, using compressed air as the power and microcomputer controlled. It can be connected with any kinds of automatic clipping machines.
This kind of sausage filling machine is with high efficiency, waterproof, conveniently and simple to operate. In addition, it is also can install another pope so that it can save the time take on the casing.
sausage filling machine
The pneumatic quantitative twisting sausage filling machine adjusts the weight of the sausages by control valve of the cylinder. We can achieve the purpose of controlling each program behavior through the button on operation panel.
This sausage stuff machine is made based on the quantitative sausage filling machine. Base on different working method, we have two type for your request: hydraulic filler and pneumatic filler.
Sausage stuff machine can not only achieve quantitative filling sausage but also automatic twisting, which change the deficiency that the past quantitative filling sausage machine can not twist at the same time.
The performance of this machine is stable, safe and reliable. It also improves the production efficiency than it previously had.

Adventage of the machine:
1. The equipment is beautiful in appearance, small and exquisite, and the contact part with the meat and the outer packaging are all made of stainless steel.
2. Easy to operate and easy to clean.
3. Quantitative accuracy.
4. Scope of application: can fill meat and small meat products.
5. Easy to clean, the quantitative can be adjusted between 30-1000g(adjusted).
6. It can fill meat and meat products, and the filling speed is adjustable, 30-50 time/min,It can reach 150 kg/h

Related product: Sausage Smoking Oven
Model GG-1
Speed

30-50 time/min

It can reach 150 kg/h

Quantitative scope 30-1000g(adjusted)
Air Source Pressure more than 0.5Mpa
Power 220V 50HZ
Height of center 850mm
Funnel Volume 30L(Continuous feed)
Filling Pipes φ12,φ15,φ25
Dimension 650*640*1400(mm)
Weight 150kg
